GL-1800S

STANDARD STAINLESS STEEL MAGNET

GEM Logo
  • Operating voltage 12 or 24Vdc
  • Stainless Steel
  • Holding force up to 1800lbs (818kg)
  • Surface mount on outswing doors
  • Weather resistant: IP67
  • Vandal resistant

Description

  • Voltage tolerance: ±15%.
  • Current draw: 500mA at 12Vdc, 250mA at 24Vdc (at temperature 20°C).
  • Operating temperature: -10~55°C (14 to 131°F).
  • Lock’s surface temperature: Current temperature ±20% (when power is on).
  • Humidity: 0~95% non-condensing.
  • Weight: 8.0kg (approx).
CP21-N Wiring Diagram

Additional information

Weight 8 kg
Dimensions 284 × 72 × 47.5 mm
