EPX-10

STANDALONE PROXIMITY

  • Operating voltage 12Vdc
  • ABS Plastic
  • Allows up to 2000 users
  • Weather resistant: IP67
  • Infrared programmer

Description

  • Power consumption: DC 12-15V, Current:150mA.
  • RF Frequency: 125 KHz.
  • With internal EM reader.
  • Unlock output delay time: 0~99 seconds.
  • Output: 1 relay.
  • Relay rating: 2A/12Vdc.
  • Read range: 5 to 10 cm.
  • Infrared keypad operation.
  • Built-in anti-tamper function.
  • Hand held programmer (EPX10-HP).
CP21-N Wiring Diagram

Additional information

Dimensions 86 × 86 × 21 mm
