CM-RQE70

INFRARED EXIT SENSOR

CAMDEN Logo
  • Operating voltage 12~24Vdc/Vac
  • Active infrared
  • Installation height 3000mm (9.8ft max)
  • IP45 Weather resistance
  • Response speed 0.1~0.2s
SKU: cm-rqe70 Categories: , Tags: , ,

Description

  • Voltage tolerance: ±10%.
  • Current draw: AC12V-1.7[VA] (Max), DC12V-110[mA] AC24V-2.1[VA] (Max), DC24V-60 [mA] (at temperature 20°C).
  • Operating temperature: -20~60°C (-20 to 140°F).
  • Humidity: 0~95% non-condensing.
  • Test input 6[mA] (Max)@24[VDC]
  • Relay hold time 0.5 sec
  • Weight 0.35kg
CP21-N Wiring Diagram

Additional information

Weight 0.25 kg
Dimensions 45 × 360 × 45 mm
