GK1100

ELECTRIC RELEASE

GEM Logo
  • Operating voltage 12~28Vac/Vdc
  • Material: Metal surface
  • Fail-Safe/Fail-Secure (Selectable)
  • Long life solenoid
  • 17mm maximum latch throw
  • Lock & unlock / door status output
  • Suitable with panic bar (Latch)
SKU: gk1100 Categories: , Tag:

Description

  • Voltage tolerance: ±15%.
  • Current draw: 230mA at 12Vdc, 140mA at 28Vdc, 440mA at 12Vac, 230mA at 28Vac (at temperature 20°C).
  • Operating temperature: -10~45°C (14 to 131°F).
  • Lock’s surface temperature: Current temperature ±20% (when power is on).
  • Reed switch rating: 1A/125Vac.
  • Humidity: 0~95% non-condensing.
  • Tested to 1,000,000 cycles (solenoid).
  • 1500lbs jaw strength pulls testing.
  • Net Weight: 752g.
CP21-N Wiring Diagram

Additional information

Weight 0.752 kg
Dimensions 232 × 40 × 20 mm
