SOLENOID ELECTRIC BOLT
- Operating voltage 12Vdc
- Fail-Safe
- Auto-relocking timer delay: 0, 3, 6 or 9 seconds
10423
Description
- Voltage tolerance: ±10%.
- Current draw: Pull in 1A, Holding 0.4A at 12Vdc (at temperature 20°C).
- Operating temperature: -10~45°C (14 to 131°F).
- Lock’s surface temperature: Current temperature ±20% (when power is on).
- Magnetic bolt status output indicates bolt locked or unlocked status (SPDT rated 3A at 30Vdc).
- Humidity: 0~95% non-condensing.
- Tested to 500,000 cycles.
- Horizontal or vertical installation.
- Weight: 1.2kg (approx).
Additional information
| Weight | 1.2 kg |
|---|---|
| Dimensions | 210 × 41 × 25 mm |
