'A' Range Magnets
A-10060DS-BLK
UNMONITORED DOUBLE STANDARD MAGNET WITH DOOR STATUS IN BLACK
- Operating voltage 12~24Vdc (Selectable)
- Architectural Black Finish
- Aluminium housing
- Holding force up to 2 x 1200lbs (544Kg)
- Electro-less nickel plated armature
- Door status: An independent contact that works separately from the magnet to show door status not lock status
A-10060-BLK
UNMONITORED DOUBLE STANDARD MAGNET IN BLACK
- Operating voltage 12~24Vdc (Selectable)
- Architectural Black Finish
- Aluminium housing
- Holding force up to 2 x 1200lbs (544Kg)
- Electro-less nickel plated armature
A-10040DS-BLK
MONITORED DOUBLE STANDARD MAGNET WITH DOOR STATUS IN BLACK
- Operating voltage 12~24Vdc (Selectable)
- Architectural Black Finish
- Aluminium housing
- Holding force up to 2 x 1200lbs (544Kg)
- Electro-less nickel plated armature
- Status LED: RED and GREEN
- Door status: An independent contact that works separately from the magnet to show door status not lock status
A-10040-BLK
MONITORED DOUBLE STANDARD MAGNET IN BLACK
- Operating voltage 12~24Vdc (Selectable)
- Architectural Black Finish
- Aluminium housing
- Holding force up to 2 x 1200lbs (544Kg)
- Electro-less nickel plated armature
- Status LED: RED and GREEN
A-10020DS-BLK
MONITORED STANDARD MAGNET WITH DOOR STATUS IN BLACK
- Operating voltage 12~24Vdc (Selectable)
- Aluminium housing
- Electro-less nickel plated armature
- Holding force up to 1,200lbs (545Kg)
- Door status: An independent contact that works separately from the magnet to show door status not lock status
- Status LED: RED and GREEN
A-10010DS-BLK
UNMONITORED STANDARD MAGNET WITH DOOR STATUS IN BLACK
- Operating voltage 12~24Vdc (Selectable)
- Architectural Black Finish
- Aluminium housing
- Electro-less Nickel Plated Armature
- Fail-Safe (Power-to-Lock)
- Holding force up to 600lbs (272Kg)
- Door status: An independent contact that works separately from the magnet to show door status not lock status
A-10010-BLK
UNMONITORED STANDARD MAGNET IN BLACK
- Operating voltage 12~24Vdc (Selectable)
- Aluminium housing
- Architectural Black Finish
- Electro-less nickel plated armature
- Holding force up to 1,200lbs (545Kg)
A-10001DS-BLK
UNMONITORED MINI MAGNET IN BLACK WITH DOOR STATUS
- Operating voltage 12~24Vdc (Selectable)
- Architectural Black Finish
- Aluminium housing
- Electro-less Nickel Plated Armature
- Fail-Safe (Power-to-Lock)
- Holding force up to 600lbs (272Kg)
- Door status: An independent contact that works separately from the magnet to show door status not lock status
A-10005DS-BLK
MONITORED DOUBLE MINI MAGNET WITH DOOR STATUS IN BLACK
- Operating voltage 12~24Vdc (Selectable)
- Aluminium housing
- Architectural Black Finish
- Fail-Safe (Power to Lock)
- Holding force up to 600lbs x 2 (272Kg x 2)
- Electro-less Nickel Plated Armature
- Status LED: RED and GREEN
- Door status: An independent contact that works separately from the magnet to show door status not lock status
A-10005-BLK
MONITORED DOUBLE MINI MAGNET IN BLACK
- Operating voltage 12~24Vdc (Selectable)
- Aluminium housing
- Architectural Black Finish
- Fail-Safe (Power to Lock)
- Holding force up to 600lbs x 2 (272Kg x 2)
- Electro-less Nickel Plated Armature
- Status LED: RED and GREEN
- Door status: An independent contact that works separately from the magnet to show door status not lock status
A-10004DS-BLK
UNMONITORED DOUBLE MINI MAGNET WITH DOOR STATUS IN BLACK
- Operating voltage 12~24Vdc (Selectable)
- Architectural Black Finish
- Aluminium housing
- Fail-Safe (Power to Lock)
- Holding force up to 600lbs x 2 (272Kg x 2)
- Electro-less Nickel Plated Armature
- Door status: An independent contact that works separately from the magnet to show door status not lock status
A-10004-BLK
UNMONITORED DOUBLE MINI MAGNET IN BLACK
- Operating voltage 12~24Vdc (Selectable)
- Architectural Black Finish
- Aluminium housing
- Fail-Safe (Power to Lock)
- Holding force up to 600lbs x 2 (272Kg x 2)
- Electro-less Nickel Plated Armature
